362MD MEDICAL TABLET
Compact, Antimicrobial, ANSI/AAMI ES60601-1 Certified Tablet for Efficient Operations
The 362MD handheld Medical Tablet features the integration of a brilliant 6" capacitive touch screen and an energy-efficient Intel® processor within a compact, lightweight, durable package. With built-in smart card reader, back camera and Wi-Fi as well as optional data capture modules, this rugged medical tablet offers health professionals an effective tool to monitor, record and retrieve patient information.
Product ConfiguratorFeatures
- 6” capacitive touch screen, digital pen support
- Intel® Pentium® Silver quad-core processor
- Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu operating system
- NIST compliant BIOS available
- ANSI/AAMI ES60601-1 certified with antimicrobial enclosure
- IP65-rated for water and dust resistance
- MIL-STD-810H for shock and vibration protection
- Built-in back camera
- Built-in smart card/CAC reader
Major Options
- NFC/RFID reader
- 2D barcode scanner; reads 1D also
Specifications
System
-
CPU
Intel® Pentium® Silver Quad-Core, 1.10 GHz (up to 2.70 GHz)
-
RAM
8GB
-
Storage
256GB Flash
-
Operating System
Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu
-
NIST Compliance
NIST Compliant BIOS Available
-
Display
6” LED-backlit (350 nits) touchscreen
-
Display Resolution
720 x 1440
-
WLAN
Wi-Fi 802.11ac, 2.4/5 GHz Dual Band
-
Buttons
1 Power Button, 2 Trigger Buttons
-
Camera
8 MP Back Camera
I/O PORTS
-
USB Port
1 x USB Type-C
(data transmitting and charging; data transmitting only available in one insertion direction) -
Smart Card/CAC Reader
Full Slot (Reads ISO 7816 T=0, T=1); 1.8/3/5V Smart Card
MECHANICAL AND ENVIRONMENTAL
-
AC/DC Adapter
Input: 100 – 240V AC; Output: 20V DC, 3A
-
Battery Pack
Hot-Swappable Battery (3100mAh)
-
Enclosure
ABS + PC Plastic; Antimicrobial Enclosure
-
Dimensions (H x W x D)
7.6 x 3.7 x 1.2 in/192 x 95 x 31 mm
-
Weight
1.1 lbs/485 g
-
Durability
IP65 and MIL-STD-810H Certified
-
Regulatory
FCC/IC, CE/CB, RCM, ANSI/AAMI ES60601-1
-
Temperature
Operation: -10°C ~ 50°C (14°F ~ 122°F );
Storage: -50°C ~ 70°C (-58°F ~ 158°F) -
Humidity
0% ~ 90% Non-Condensing
MAJOR OPTIONS SPECS
-
BARCODE SCANNER
2D Barcode Scanner (Reads 1D & 2D)
-
NFC/RFID READER
HF 13.56 MHz, ISO 15693, 14443A(B) & 18000-3 Mode 1 or Dual Frequency (Reads both 125 KHz & 13.56 MHz Credentials)
Accessories
Digital Pen
Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.
Desktop Charging Cradle
Charge one handheld tablet and one battery pack; ports for Power, USB, video-out, and Ethernet.
Battery Pack
3100mAh battery pack.
AC/DC Power Adapter with Power Cord
Facilitates Tablet operation or battery recharge. USB Type-C connector.
