313Y/MD RUGGED 2-IN-1 MEDICAL TABLET

Slim, Antimicrobial, ANSI/AAMI ES60601-1 Certified Tablet for Efficient Operations

The 313Y/MD Rugged 2-in-1 Medical Tablet features the integration of a brilliant 13.3" capacitive touch screen and a high performance, energy-efficient Intel® Core™ i series processor within a slim, lightweight, durable package. With built-in front and back cameras, Wi-Fi as well as optional data capture modules, this medical tablet offers health professionals an effective tool to monitor, record and retrieve patient information. With its large, vivid display, the 313Y/MD Rugged Medical Tablet shows a wide work area and detailed application interface to enhance user experience and workflow.

Product Configurator

Features

  • 13.3" Full-HD capacitive touch screen, 1000 nits, digital pen support
  • Intel® Core™ i processor
  • Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu operating system
  • NIST compliant BIOS available
  • ANSI/AAMI ES60601-1 certified with antimicrobial enclosure
  • Docking keyboard option for 2-in-1 (tablet/ laptop) applications
  • Hot swappable battery pack
  • IP65-rated for water and dust resistance
  • MIL-STD-810G for shock and vibration protection
  • Built-in front and back cameras
  • Built-in smart card/CAC reader

Major Options

  • Barcode scanner
  • NFC/RFID reader
  • 4G LTE/AWS

Specifications

SYSTEM
  • CPU

    Intel® Core™ i7-1355U, 10-Core, up to 5.0 GHz
    Intel® Core™ i5-1335U, 10-Core, up to 4.6 GHz

  • RAM

    8GB to 16GB

  • Storage

    256GB to 512GB Flash

  • Operating System

    Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu

  • NIST Compliance

    NIST Compliant BIOS Available

  • Display

    13.3” LED-backlit, High-Brightness (1000 nits) Touchscree

  • Display Resolution

    1920 x 1080

  • WLAN

    Wi-Fi 802.11ax, 2.4/5 GHz Dual Band

  • Control Switch and Buttons

    1 Power Button, 2 Brightness Control Buttons, 5 Programmable Buttons

  • Microphone

    Built-In Microphone

  • Speaker

    Built-In Speaker

  • Camera

    5 MP Front Camera & 8 MP Back Camera

I/O INTERFACES
  • USB 3.0 Port

    3 x USB 3.0,
    1 x USB Type C

  • Headphone-out

    1

  • Ethernet Port

    1 (RJ45)

  • DC-in

    1

  • Smart Card/ CAC Reader

    Full Slot (Reads ISO 7816 T=0, T=1); 1.8/3/5V Smart Card

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100-240V AC; Output: 20V DC, 3A

  • Battery Pack

    Hot-Swappable Battery (5400mAh)

  • Enclosure

    ABS + PC Plastic and Magnesium-Aluminum Alloy; Antimicrobial Enclosure

  • Dimensions (H x W x D)

    10.1 x 13.2 x 0.8 in/256 x 335 x 21 mm

  • Weight

    3.97 lbs/1.8 kg

  • Durability

    IP65 and MIL-STD-810G Certified

  • Regulatory

    FCC/IC, CE/CB, RCM, ANSI/AAMI ES60601-1

  • Temperature

    Operation*: -10°C ~ 60°C (14°F ~ 140°F),
    Optional: -30°C ~ 60°C (-22°F ~ 140°F)
    Storage: -55°C ~ 70°C (-67°F ~ 158°F)
    *For battery safety and optimal functionality and performance, the recommended usage temperature range is from -10°C to 45°C (14°F to 113°F)

  • Humidity

    0% ~ 90% Non-Condensing

MAJOR OPTIONS SPECS
  • BARCODE SCANNER

    2D Barcode Scanner (Reads 1D & 2D)

  • NFC/RFID READER

    Dual Frequency( Reads 125 KHz & 13.56 MHz Credentials)

  • MOBILE BROADBAND

    4G LTE/AWS

Accessories

    Detachable Keyboard
    Docking Keyboard

    With power and I/O ports; instantly pairs, ideal for 2-in-1 applications.

    6-Bay External Battery Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates Tablet operation or battery recharge. USB Type-C connector.

    Desktop Charging Cradle
    Desktop Charging Cradle

    With alternative DC-IN and Type-C power input options and a comprehensive set of I/O interfaces for Ethernet, HDMI, USB, and COM.

    Tablet Mount Cradle
    Tablet Mount Cradle

    Offers Tablet storage and security with power supply and I/O ports.

    External Battery Pack
    Battery Pack

    Hot swappable, 60W or 90W.

    Digital Pen
    Digital Pen

    Dimension: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

    Battery Holster
    3-Slot Battery Holster

    Supplies powers to the system and peripherals (e.g., Zebra mobile printer and Welch Allyn vital sign monitor).

    Digital Pen
    10.1”/11.6”/13.3” Screen Protector

    User-replaceable film screen protector to protect the display from scratches and repeated use. Comes with microfiber cleaning cloth and dust-absorber to make the applying process an easy task.

    X-Handstrap
    X-Handstrap

    Designed to securely hold the Tablet; soft plastic, easy to clean, for left- or right-handed users.
