362Q Handheld Rugged Tablet
Slim, Rugged, Multi-functional Wireless Computing
The DT Research 362Q Handheld Rugged Tablet features the integration of a brilliant 6" capacitive touchscreen, Android operating system, and a high performance yet energy efficient octa-core processor within a slim, lightweight, durable package. With Wi-Fi as well as options for barcode scanner, back camera, GPS, NFC, and UHF RFID reader, this robust tablet offers seamless information capture and transmission for improved workflow. Rated IP65 and MIL-STD-810G certified, the 362Q Handheld Rugged Tablet provides reliable operation in harsh, mission-critical environments.
Product ConfiguratorFeatures
- 6” capacitive touchscreen, digital pen support
- Qualcomm octa-core processor
- Android operating system
- Hot-swappable battery pack
- IP65-rated for water and dust resistance
- MIL-STD-810G for shock and vibration protection
Major Options
- 8 MP Back Camera
- Barcode Scanner
- NFC/RFID Reader
- GPS
Specifications
System
-
CPU
Qualcomm 8-core processor (2.0GHz)
-
RAM
4GB
-
Storage
64GB flash
-
Operating System
Android 9/10
-
Display
6" LED-Backlit (350 nits) touchscreen
-
Display Resolution
720 x 1440
-
WLAN
Wi-Fi 802.11ac, 2.4/5 GHz Dual Band
-
Control Switch and Buttons
1 power button, 2 trigger buttons
I/O PORTS
-
USB Port
1 x USB Type-C (data transmitting and charging; data transmitting only available in one insertion direction)
-
Micro SD Slot
1
MECHANICAL AND ENVIRONMENTAL
-
AC/DC Adapter
Input: 100 – 240V AC; Output: 20V DC, 3.25A
-
Battery Pack
Hot-Swappable Battery (3100mAh)
-
Enclosure
ABS + PC plastics
-
Dimensions (H x W x D)
7.6 x 3.7 x 1.2 in/192 x 95 x 31 mm
-
Weight
1.1 lbs/480 g
-
Durability
IP65 and MIL-STD-810G
-
Regulatory
FCC Class B, RoHS compliant
-
Temperature
Operation: -10°C ~ 50°C (14°F ~ 122°F );
Storage: -50°C ~ 70°C (-58°F ~ 158°F) -
Humidity
0% ~ 90% non-condensing
MAJOR OPTIONS SPECS
-
CAMERA
8 MP Back Camera
-
BARCODE SCANNER
2D Barcode Scanner; Reads 1D Also
-
NFC/RFID READER
HF 13.56MHz, ISO Standard 15693, 14443A(B) & 18000-3 Mode-1
-
GPS
Yes
Accessories
Digital Pen
Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.
Desktop Charging Cradle
Charge one handheld tablet and one battery pack; ports for Power, USB, video-out, and Ethernet.
4-Bay System Gang Charger
Multi-bay charger, capable of charging up to 4 tablets simultaneously.
6-Bay Battery Gang Charger
Multi-bay charger, capable of charging up to 6 battery packs simultaneously.
Trigger Grip for Barcode Scanner
Triggers the barcode scanner module.
Trigger Grip for UHF RFID Reader
Supports 30 feet UHF RFID Reader read distance.
Charging Cradle for UHF RFID Reader Trigger Grip
Charges the trigger grip with DT362 tablet.
Charging Cradle for Trigger Grip
Supports to charge the trigger grip (without the antenna) with DT362 tablet.
Battery Packs
3100mAh battery packs.
AC/DC Power Adapter with Power Cord
Facilitates Tablet operation or battery recharge. USB Type-C connector.
