DT312PA Rugged Tablet

Slim, Rugged, Multi-functional Wireless Computing

The DT312PA Rugged Tablet features the integration of high-brightness 11.6" touchscreen and a high performance, energy-efficient Intel_® Core™ Ultra processor within a slim, lightweight, durable package. With a built-in Wi-Fi module as well as optional front/ back cameras, barcode scanner and GNSS data capture modules, this robust tablet offers seamless information capture and transmission for improved workflow. Rated IP65, MIL-STD-810H/461G certified with a wide temperature range, the DT312PA Rugged Tablet provides reliable operation in harsh, mission-critical environments.

Product Configurator

Features

11.6” sunlight readable touchscreen, digital pen support
Intel_® Core™ Ultra 5/7 processor
Microsoft_® Windows_® 11 IoT Enterprise operating system
NIST compliant BIOS available
Hot-swappable battery for 24/7 operation
IP65-rated for water and dust resistance
MIL-STD-810H for shock and vibration protection
MIL-STD-461G for EMI and EMC tolerance
Slim keyboard option for 2-in-1 applications
Quick Access SSD

Major Options

5 MP Front Camera and 13 MP Back Camera
4G LTE/5G
GPS Module
2D Barcode Scanner (Reads 1D and 2D)

*4G Module cannot build on same device with 2D Scanner and GPS Module.

Specifications

System

CPU

Intel_®Core™ Ultra 5 Processor 225U, 12 core (up to 4.80 GHz)
Intel_®Core™ Ultra 7 Processor 255U, 12 core (up to 5.20 GHz)
RAM

16G to 32G LPDDR5
Storage

512GB to 4TB
*Support quick access SSD function to easily replace the SSD without opening the back cover
Operating System

Microsoft_® Windows_® 11 IoT Enterprise
NIST Compliance

NIST Compliant BIOS Available
Display

11.6” LED-Backlit, Sunlight-Readable (1000 nits) Touchscreen
Display Resolution

1920 x 1080
Microphone

Built-In Microphone with DSP for Real-Time Video Streaming
Speaker

Built-In Speaker
Switches and Buttons

1 x Power Button, 2 x Brightness Buttons, 5 x Programmable Buttons

Network Interface

WLAN

Wi-Fi 802.11ax, 2.4/5/6 GHz Three Band
BT

5.3

I/O Ports

USB Port

1 x USB3.2 (Type-A), 1 x USB3.2 latest USB/charging
Ethernet Port

1 x Ethernet 10/100/1000MB Base-T LAN
DC IN Jack

1
24-pin Fischer Minimax Connector (Optional)

1 x USB2.0, COM port, RJ45, Power 5A (in), and Power 2A (out)

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter

Input: 100 to 240V AC; Output: 19V DC, 3.42A (65W)
Battery Pack

Hot-Swappable Battery (11.4V, 3800mAh)
(Optional) 60W Hot-Swappable Battery (11.4V, 5400mAh)
(Optional) 90W Hot-Swappable Battery, (11.4V, 8000mAh)
Enclosure

ABS + PC Plastic and Magnesium-Aluminum Alloy
Dimensions (H x W x D)

8.3 x 12.4 x 0.78 in/212 x 316 x 20 mm
Weight

3.43 lbs/1.55 kg
Durability

IP65, MIL-STD-810H and MIL-STD-461G Certified
Regulatory

CE, FCC Class B, IC, CB, RCM, IEC 60601-1, IEC62680, EPEAT, Energy star 8.0
Temperature

Operation*: -10°C to 60°C (14°F to 140°F)
Storage: -50°C to 70°C (-58°F to 158°F)
Humidity

0% to 90% Non-Condensing

MAJOR OPTIONS SPECS

Barcode Scanner

2D Barcode Scanner (Reads 1D and 2D)
Camera

5 MP Front Camera and 13 MP Back Camera
GNSS

GPS
Mobile Broadband

4G LTE/AWS

Accessories

Detachable Slim Keyboard

Slim and lightweight with magnetic hinge to effortlessly attach/detach to the DT312RP rugged tablet.

Tablet Mount Cradle

Offers Tablet storage and security with power supply and I/O ports.

Battery Gang Charger

Simultaneously charge 6 external batteries.

Digital Pen

Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

Desktop Charging Cradle

With I/O ports supporting power, USB, COM, and Ethernet.

Battery Charger Kit with AC Adapter and Power cord

Recharges battery pack "offline" without affecting tablet use.

Screen Protector

User-replaceable film screen protector to protect the display from scratches and repeated use. Comes with microfiber cleaning cloth and dust-absorber to make the applying process an easy task.
