DT381RP RUGGED TABLET

Slim, Rugged, Multi-functional Wireless Computing

Energy Star mark

The DT381RP Rugged Tablet features the integration of a LED-backlit, high-brightness (800 nits) 8” touchscreen and a powerful Intel® Core™ i processor within a slim, lightweight, and durable enclosure. With the built-in Wi-Fi, BT and optional advanced data capture modules, DT381RP is capable of operating at high performance while providing optimized operating efficiency. Rated IP65, MIL-STD-810H and MIL-STD-461G certification, the DT381RP Rugged Tablet is ideal for operations in harsh, mission-critical environments.

Product Configurator

Features

  • 8" LED-Backlit, high-brightness (800 nits) touchscreen, digital pen support
  • Intel® Core™ i processor
  • Microsoft® Windows® 10/11 operating system
  • NIST compliant BIOS available
  • IP65-rated for water and dust resistance
  • MIL-STD-810H for shock and vibration protection
  • MIL-STD-461G for EMI and EMC tolerance
  • Hot-swappable battery pack
  • Energy Star 8.0 certified

Major Options

  • Front and back cameras
  • Long-range BT
  • GPS module
  • 4G LTE/AWS
  • Wider operating temperature range
  • * Back camera and LRBT cannot be built onto same device.

Specifications

System
  • CPU

    Intel® Core™ i5-1335U, 10-core, up to 4.6 GHz
    Intel® Core™ i7-1355U, 10-core, up to 5 GHz

  • RAM

    16GB

  • Storage

    512GB to 1TB SSD

  • Operating System

    Microsoft® Windows® 10/11 IoT Enterprise

  • NIST Compliance

    NIST compliant BIOS available

  • Trusted Platform Module

    TPM 2.0

  • Display

    8" LED-backlit, high-brightness (800 nits) touchscreen

  • Display Resolution

    1280 x 800

  • Speaker

    Built-in speaker

  • Buttons

    1 x power button, 2 x brightness buttons, 4 programmable buttons

Network Interface
  • WLAN

    Wi-Fi 802.11ax, 2.4/5 GHz dual band

  • BT

    BT 5.2

I/O Ports
  • USB Port

    1 x USB 3.2 Gen 1 Type A, 1 x latest USB/charging

  • Ethernet

    1 (Ethernet 10/100/1000MB Base-T LAN)

  • Audio Jack

    1 (3.5 mm)

  • SD Card Slot

    1 x micro SD card slot

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100 to 240V AC; Output: 19V DC, 3.25A

  • Battery Pack

    Hot-Swappable Battery (7.6V, 6000mAh)
    (Optional) 60W Hot-swappable battery (11.4V, 5400mAh)
    (Optional) 90W Hot-swappable battery (11.4V, 8000mAh)

  • Enclosure

    ABS + PC plastic

  • Dimensions (H x W x D)

    5.8 x 9.2 x 1.0 in/147.3 x 234 x 25.5 mm

  • Weight

    2.65 lbs/1.2 kg

  • Durability

    IP65, MIL-STD-810H and MIL-STD-461G certified

  • Regulatory

    FCC Class B, CE, RoHS, Energy Star 8.0 compliant

  • Temperature

    Operation*: -10°C to 60°C (14°F to 140°F)
    Optional -30°C to 60°C (-22°F to 140°F)
    Storage: -50°C to 70°C (-58°F to 158°F)
    *For battery optimal functionality and performance, the recommended usage temperature range is from 0°C to 50°C (32°F to 122°F)

  • Humidity

    0% to 90% non-condensing

MAJOR OPTIONS SPECS
  • Camera

    8 MP front and back cameras w/ auto focus, white balance, gain control, and Exposure Control

  • Long-Range BT

    Class 1 BT (1000 ft.)

  • GNSS

    GPS

  • Mobile Broadband

    4G LTE/AWS

Accessories

    Desktop Charging Cradle
    Desktop Charging Cradle

    Docking support with ports for Power, USB, HDMI output and Ethernet.

    Tablet Mount Cradle
    Wall/Vehicle Mount Cradle

    Designed to be attached with the Wall/Vehicle Mount Cradle.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates battery recharge or Tablet operation through direct connection to the Tablet or via the Power Jack in the Charging Cradle. (Choice of North America, UK or EU power cord).

    AC/DC Power Adapter with Power Cord
    Battery Pack

    Hot-swappable, 60W or 90W.

    Battery Charger Kit with AC Adapter and Power cord
    Battery Charger Kit with AC Adapter and Power cord

    Recharges battery pack "offline" without affecting tablet use.

    Battery Gang Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    Digital Pen
    Digital Pen

    Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

    Shoulder Strap for Tablets
    Shoulder Strap for Tablets

    Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.

    Digital Pen
    Tempered Glass Screen Protector

    Protects screen from scratches, impacts, and fingerprints with ultra-clear, high-strength tempered glass.
