* Back camera and LRBT cannot be built onto same device.
CPU
Intel® Core™ i5-1335U, 10-core, up to 4.6 GHz
Intel® Core™ i7-1355U, 10-core, up to 5 GHz
RAM
16GB
Storage
512GB to 1TB SSD
Operating System
Microsoft® Windows® 10/11 IoT Enterprise
NIST Compliance
NIST compliant BIOS available
Trusted Platform Module
TPM 2.0
Display
8" LED-backlit, high-brightness (800 nits) touchscreen
Display Resolution
1280 x 800
Speaker
Built-in speaker
Buttons
1 x power button, 2 x brightness buttons, 4 programmable buttons
WLAN
Wi-Fi 802.11ax, 2.4/5 GHz dual band
BT
BT 5.2
USB Port
1 x USB 3.2 Gen 1 Type A, 1 x latest USB/charging
Ethernet
1 (Ethernet 10/100/1000MB Base-T LAN)
Audio Jack
1 (3.5 mm)
SD Card Slot
1 x micro SD card slot
AC/DC Adapter
Input: 100 to 240V AC; Output: 19V DC, 3.25A
Battery Pack
Hot-Swappable Battery (7.6V, 6000mAh)
(Optional) 60W Hot-swappable battery (11.4V, 5400mAh)
(Optional) 90W Hot-swappable battery (11.4V, 8000mAh)
Enclosure
ABS + PC plastic
Dimensions (H x W x D)
5.8 x 9.2 x 1.0 in/147.3 x 234 x 25.5 mm
Weight
2.65 lbs/1.2 kg
Durability
IP65, MIL-STD-810H and MIL-STD-461G certified
Regulatory
FCC Class B, CE, RoHS, Energy Star 8.0 compliant
Temperature
Operation*: -10°C to 60°C (14°F to 140°F)
Optional -30°C to 60°C (-22°F to 140°F)
Storage: -50°C to 70°C (-58°F to 158°F)
*For battery optimal functionality and performance, the recommended usage temperature range is from 0°C to 50°C (32°F to 122°F)
Humidity
0% to 90% non-condensing
Camera
8 MP front and back cameras w/ auto focus, white balance, gain control, and Exposure Control
Long-Range BT
Class 1 BT (1000 ft.)
GNSS
GPS
Mobile Broadband
4G LTE/AWS
Docking support with ports for Power, USB, HDMI output and Ethernet.
Designed to be attached with the Wall/Vehicle Mount Cradle.
Facilitates battery recharge or Tablet operation through direct connection to the Tablet or via the Power Jack in the Charging Cradle. (Choice of North America, UK or EU power cord).
Hot-swappable, 60W or 90W.
Recharges battery pack "offline" without affecting tablet use.
Simultaneously charge 6 external batteries.
Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.
Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.
Protects screen from scratches, impacts, and fingerprints with ultra-clear, high-strength tempered glass.
