311Q RUGGED TABLET

Slim, Rugged, Multi-functional Wireless Computing

The 311Q Rugged Tablet features the integration of a high brightness 11.6”capacitive touch screen, Android operating system,and a high performance yet energy-efficient octa-core processor within a slim, lightweight, durable package. With a built-in back camera, Wi-Fi and Bluetooth, as well as options for front camera, barcode scanner, long range Bluetooth and GPS, this rugged tablet offers seamless information capture and transmission for improved workflow. Rated IP65, MIL-STD-810G and HERO certified with wide temperature range, the 311Q Rugged Tablet provides reliable operation in harsh, mission-critical environments.

Product Configurator

Features

  • 11.1" Full-HD capacitive touch screen, 1000 nits, digital pen support
  • Qualcomm octa-core processor
  • Android operating system
  • High capacity, hot-swappable battery pack
  • Built-in back camera
  • IP65 rated and MIL-STD-810G certified
  • HERO (Hazard of Electromagnetic Radiation to Ordnance) certified
  • Detachable keyboard option for 2-in-1 applications

Major Options

  • Front camera
  • 2D barcode scanner; reads 1D also
  • NFC/RFID reader
  • GPS
  • 4G LTE/AWS

Specifications

System
  • CPU

    Qualcomm Octa-Core, 2.0GHz

  • RAM

    4GB

  • Storage

    64GB Flash

  • Operating System

    Android 9.0 and 10

  • Display

    11.6” LED-backlight, high-brightness (1000 nits) screen with capacitive touch, outdoor viewable

  • Display Resolution

    1920 x 1080

  • Network Interface

    Wi-Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.1 LE

  • Control Switch and Buttons

    1 power button, 2 brightness control buttons, 5 programmable buttons

  • Speaker

    Built-in speaker

  • Back Camera

    8 megapixel back camera

I/O PORTS
  • USB Port

    USB 2.0 x 1, USB 3.0 x 1, USB Type C x 1 (data transmitting and charging)

  • Headset Jack

    1

  • SD Slot

    1 micro SD card slot

  • Ethernet

    1 RJ45 connector for Ethernet

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100 – 240V AC; Output: 20V DC, 3.25A

  • Battery Pack

    Hot swappable battery, 7.6V, 6000mAh

  • Enclosure

    ABS + PC plastics and magnesium-aluminum alloy

  • Dimensions (H x W x D)

    8.3 x 12.4 x 0.86 in/ 212 x 316 x 21.9 mm

  • Weight

    3.5 lbs/ 1.6 kg

  • Durability

    IP65 and MIL-STD-810G certified

  • Regulatory

    FCC Class B, CE, RoHS compliant

  • Temperature

    Operation: -10°C to 50°C (-14°F to 122°F)
    Storage: -55°C to 70°C (-67°F to 158°F)

  • Humidity

    0% – 90% non-condensing

MAJOR OPTIONS SPECS
  • BARCODE SCANNER

    2D barcode scanner; reads 1D also

  • FRONT CAMERA

    2 megapixel front camera

  • NFC/RFID READER

    HF 13.56MHz, ISO standard 15693, 14443A(B) & 18000-3 mode-1

  • GPS

    Yes

  • MOBILE BROADBAND

    4G LTE/AWS

Accessories

    Detachable Keyboard
    Docking Keyboard

    With ports for Power, LAN, HDMI output and USB; designed to connect to the DT311Y/NV rugged tablets, instantly pairs, ideal for 2-in-1 applications.

    Battery Gang Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    Digital Pen
    Digital Pen

    Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

    Tablet Mount Cradle
    Tablet Mount Cradle

    Offers Tablet storage and security with power, HDMI-out, COM, Ethernet pass-through, and USB ports; power supply is not included.

    Battery Charger Kit with AC Adapter and Power cord
    Battery Charger Kit with AC Adapter and Power cord

    Recharges battery pack "offline" without affecting tablet use.

    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle
    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle

    Includes ACC-008-50T and DTR packaging. Designed to be attached with the Wall/Vehicle Mount Cradle. The Keyboard Mounting Kit can be folded up when not in use.

    Carrying Case
    Carrying Case

    Open-to-use design with foldable tabletop stand. Made of 1680 denier nylon fiber with water-repellent coating.

    Carrying Case and Portfolio
    Carrying Case and Portfolio

    Added protection and secure portability to guard Rugged Tablets from scratches, bumps, and drops.

    Screen Protector
    Screen Protector

    Advanced coating technologies, provides anti‐reflection and high transparency to keep bright and crisp visuals while guarding against scratches and physical damage.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates Tablet operation or battery recharge. USB Type-C connector.

    Shoulder Strap for Tablets
    Shoulder Strap for Tablets

    Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.

    Automobile Power Adapter by LIND
    Automobile Power Adapter by LIND

    Output voltage 65W/ 19V Input: 11-16V DC.

    X-Handstrap
    X-Handstrap

    Designed to securely hold the Tablet. Made of soft plastic, easy to clean. For left- or right-handed users.
